Researchers in Spain and Scotland have been experimenting with the strength qualities of modern forms of unfired clay bricks, discovering what have been dubbed wool bricks. They are an almost zero-carbon product that can be sourced using local materials, and may just be a step in the right direction towards a greener future of building.
More than nine billion conventional bricks are manufactured every year to meet our insatiable construction demand. They are a major source of polluting greenhouse gases, being traditionally kiln-fired to increase their strength, which uses huge amounts of wood, coal and natural gas. Brick kilns release toxic fumes containing suspended particulates with high concentrations of carbon monoxides and oxides of sulfur (SOx), which can have serious health and environmental impacts.
It has been estimated that per brick, around 1.4 pounds of carbon is released into the atmosphere and this is having devastating impacts on air pollution, particularly in developing countries like India and China. After vehicle emissions, the brick manufacturing industry is one of the main sources of SOx emissions, not to mention the wood resources needed to fire the kilns and the impact this has on deforestation across the globe.
But there’s a movement to come up with more sustainable and alternative bricks, without the need for kiln firing, whilst still retaining the strength properties necessary for building. Untreated clay has long been used throughout history as a building material, with houses built from earth combined with plants and pebbles found in archaeological sites in Sardinia dating back to around 1,400BC.
What are wool bricks?
Wool bricks are made by adding wool fibers to the regular clay material used to make bricks, then combined with an alginate conglomerate, a natural polymer extracted from the cell walls of seaweed. They are naturally dried (rather than the energy-intensive and polluting process of firing) and the result is a brick that is less prone to cracking and less likely to warp. They have shown to be stronger than unfired, stabilized earth bricks, and when made using locally-sourced products, can be labeled as a zero-carbon brick.
Who developed wool bricks?
Carmen Galán and Carlos Rivera from the Schools of Architecture in the Universities of Seville (Spain) and Strathclyde (Glasgow, United Kingdom) are the researchers behind wool bricks. They were invented as part of a move by the two universities to find more sustainable building materials, which would at the same time improve on the mechanical qualities of conventional products: “The objective was to produce bricks reinforced with wool and to obtain a composite that was more sustainable, non-toxic, using abundant local materials, and that would mechanically improve the bricks’ strength”.
Advantages of wool bricks?
Wool bricks have been developed as part of a move towards more sustainable construction materials, with the ability for them to be manufactured without firing their most environmentally friendly quality. Compared to baked earth bricks and concrete blocks, the energy needed to create them is significantly reduced, creating a greener alternative to these conventional building materials.
Mechanical tests also indicate that wool bricks are around 37% stronger than conventional bricks made using unfired, stabilized earth. The researchers explained the addition of wool into the clay mix, saying “These fibers improve the strength of compressed bricks, reduce the formation of fissures and deformities as a result of contraction, reduce drying time and increase the bricks’ resistance to flexion.”
The result is a more durable brick, whose environmental footprint is severely reduced, without compromising on the strength of the building material.
